Roof Panel – PV Solar Compatible – Rock Wool - MW
| ||||||||||||||||||||
| ||||||||||||||||||||
|
| ||||||||||||||||||||
| Details |
| |||||||||||||||||||
Technical Specifications
Product Code : NGRP5
Design : 5 Ribs
Max. Length : 15.5 m
Coating Type : Polyesther, PVDV, Plastisol
Insulation Type : Rockwool MW
Insulation Thickness : 40-50-60-70-80-100-120-150-180-200
Thermal Permeability : 0.045 W/m K (10 °C)
Fire Class : As1d0
Density : 90-130 kg/m³ MW
FeaturesFIRE RESISTANCE
SOLAR PANEL COMPATIBLE
LOW COST
LONG LASTING
The PV Solar Roof panel features a 5-rib profile with a rib height of 37 mm. It offers high thermal insulation and superior protection against external elements. Surface coating options for the PV Solar Roof panel include Polyester, PVDF, Plastisol, and PVC. The PV Solar Roof panel has a maximum length of 15.5 meters and is available with ten insulation thickness options: 40, 50, 60, 70, 80, 100, 120, 150, 180, and 200 mm. Manufactured with PUR/PIR insulation, the panel delivers high thermal insulation performance thanks to the closed-cell structure of the PUR/PIR material. Another advantage of this structure is its vapor resistance, which ensures negligible water absorption. The PV Solar Roof panel allows for quick and easy installation. You can contact us via the available communication channels to obtain detailed information about the PV Solar Roof panel. | ||||||||||||||||||||
